Design of Floating Ball valve

The design of New lotoke's ball valve always based reliability and the service life, e.g. the key part we will using double sealing O-Ring for avoiding leakage.

Design standard: API 608 ,ISO17292.

Connection standard: ASMEB16.47/B16.5/B16.25.

Fire safe standard: API607,API6FA,ISO10497.

Range of Material

The selecting material of ball valves always based ASTM Standard, we have much experience of below material:

Normal Casting: WCB,LCB,C5,WC9,CF8,CF8M.

Normal Forging: A105,LF2,F5,F22,F304,F316.

Special Casting: M35-1,4A,CN7M,CW-12MW,CW-6MC. Special Forging: K500,F51,N08020,N10002,N06625.

Structure of Optional

A Operation

Lever operation under 6",

Gear operation when size bigger than

6",

Can choosing Pneumatic Actuator according the working condition.

B Body and bonnet

Split type floating ball valve structure can be divided into two pieces and three pieces body

C Bore

Normally ball valve is full bore,reduced bore valves can be choose in the requirements of flowing control condition.

D Connection

Flange and BW is common connection, there are RF and RTJ type in Flange connection.

E Blowout-proof stem

Make sure stem will not be blown out under pressure.

F Anti-static

The ball valve design mainly has an electrical continuity. And the ball is always in contact with the stem when it is open and close. In addition, the stem is always in contact with the body through the gland flange or top flange, the electrical will released. So this design will prevent electrostatic to making the fire.

G Fire safe design

The are double sealing in very seal parts. Fire safe valve was planned when the plant is under fire; the delicate seats were all burnt, the valve was still fixed by the exact valve ball body. This will keep the harm as low as would be prudent.

H Double sealing in

body connector

The Double sealing design in body connector used in the valves size bigger than 1 inch, make sure the valve will not leak.

initpintu_1

initpintu_2

Split Body Floating Ball Valve dimensions weights

NPS	d	L-RF	L-RTJ	L-WE	H	W	Weight(Kg)	L-RF	L-RTJ	L-WE	H	W	Weight(Kg)
1/2"	13	108	108	140	81	150	2.8	140	151	140	81	150	3
3/4"	19	117	117	152	85	150	3.7	152	165	152	85	150	4
1"	25	127	140	165	98	180	5.3	165	178	165	98	180	6.6
1 1/2"	38	165	178	190	133	280	8.3	190	203	190	133	280	12.9
2"	49	178	191	216	141	280	15	216	232	216	141	280	21.4
2 1/2"	62	191	203	241	139	400	22.5	241	257	241	139	400	32.5
3"	74	203	216	283	150	400	27	283	298	283	150	400	45
4"	100	229	241	305	223	650	44.2	305	321	305	223	650	64.8
6"	150	394	406	457	297	280	127.6	403	419	403	297	300	147.5
8"	201	457	470	521	378	280	221.8	502	518	521	378	300	287.5
10"	252	533	546	559	408	400	430	568	584	559	408	400	550
12"	303	610	622	635	430	400	680

Class		CLASS 400 Full bore						CLASS 600 Full bore
NPS	d	L-RF	L-RTJ	L-WE	H	W	Weight(Kg)	L-RF	L-RTJ	L-WE	H	W	Weight(Kg)
1/2"	13	165	167	165	66	150	3.5	165	167	165	66	150	3.5
3/4"	19	190	190	190	88	170	5	190	190	190	88	170	5
1"	25	216	216	216	90	250	7.5	216	216	216	90	250	7.5
1 1/2"	38	241	241	241	120	400	15	241	241	241	120	400	15
2"	49	292	295	292	135	400	29.4	292	295	292	135	400	29.4
2 1/2"	62	330	333	330	150	400	39.3	330	333	330	150	400	39.3
3"	74	356	359	356	164	400	58.2	356	359	356	164	400	58.2
4"	100	406	410	406	224	995	81.2	432	435	432	224	995	81.2

Class			CLASS 150 Reduced bore						CLASS 300 Reduced bore
NPS	D	d	L-RF	L-RTJ	L-WE	H	W	Weight(Kg)	L-RF	L-RTJ	L-WE	H	W	Weight(Kg)
3/4"x1/2"	19	13	117	117	152	81	150	3.5	152	165	152	81	150	3.7
1"x3/4"	25	19	127	140	165	85	150	5	165	178	165	85	150	5.8
1 1/2"x1"	38	32	165	178	190	98	180	7.5	190	203	190	98	180	10.5
2"x1 1/2"	49	38	178	191	216	133	280	10	216	232	216	133	280	16.1
2 1/2"x2"	62	49	191	203	241	141	280	16	241	257	241	141	280	24.5
3"x2"	74	49	203	216	283	141	280	21	283	298	283	141	280	34.7
3"x2 1/2"	74	62	203	216	283	139	400	28	283	298	283	139	400	44
4"x3"	100	74	229	241	305	150	400	35	305	321	305	150	400	53
6"x4"	150	100	394	406	457	223	650	73	403	419	403	223	650	100
8"x6"	201	150	457	470	521	297	280	120	502	518	521	297	300	170
10"x8"	252	201	533	546	559	378	280	200	502	518	521	378	300	250
12"x10"	303	252	610	622	635	408	400	470	568	584	559	408	400
14"x12"	334	303	686	699	762	430	400	500

Class			CLASS 400 Reduced bore						CLASS 600 Reduced bore
NPS	D	d	L-RF	L-RTJ	L-WE	H	W	Weight(Kg)	L-RF	L-RTJ	L-WE	H	W	Weight(Kg)
3/4"x1/2"	19	13	190	190	190	66	150	4	165	167	165	66	150	4
1"x3/4"	25	19	216	216	216	88	170	5.5	190	190	190	88	170	5.5
1 1/2"x1"	38	32	241	241	241	90	250	10.5	216	216	216	90	250	10.5
2"x1 1/2"	49	38	292	295	292	120	400	20	241	241	241	120	400	20
2 1/2"x2"	62	49	330	333	330	135	400	25	330	333	330	135	400	25
3"x2"	74	49	356	359	356	135	400	29	356	359	356	135	400	29
3"x2 1/2"	74	62	356	359	356	150	400	42	356	359	356	150	400	42
4"x3"	100	74	406	410	406	164	400	59	432	435	432	164	400	59
6"x4"	150	100	495	498	495	224	995	95	432	435	432	224	995	95
